The meshing of timing belt teeth in pulley grooves

Childs, T.H.C.
Dalgarno, K.W.
Hojjati, M.H.
Tutt, M.J.
Day, Andrew J.
Publication Date
1997
End of Embargo
Supervisor
Rights
© 1997 IMechE. Reproduced in accordance with the publisher's self-archiving policy.
Peer-Reviewed
Yes
Open Access status
Accepted for publication
Institution
Department
Awarded
Embargo end date
Additional title
Abstract
The work described here has been carried out to obtain a better understanding of the tooth root cracking failure mode of timing belts. Previous work has demonstrated the close dependence of this on the tooth deflections of fully meshed teeth, generated by torque transmission, but has not considered the additional distortions generated in the partially meshed conditions at entry to and exit from a pulley groove. Approximate compatibility and constitutive equations are combined with a rigorous consideration of tooth equilibrium in partial meshing to show how bending moments are generated at both exit from a driven pulley and entry to a driving pulley. Experimentally determined belt lives correlate very well with a combined measure of fully meshed tooth strain and strain due to bending at entry or exit. The analysis also shows that this strain measure reduces with increasing belt tooth stiffness, confirming the importance of a high tooth stiffness for a long belt life. Tooth force variations through the partial meshing cycle have also been predicted and compared with measurements obtained from a special strain gauge instrumented pulley. A greater pulley rotation than is predicted is required for a belt tooth to seat in a pulley groove. There is room for improvement in the modelling
Version
Published version
Citation
Childs TCH, Dalgarno KW, Hojjati MH, et al (1997) The meshing of timing belt teeth in pulley grooves. Proceedings of the Institution of Mechanical Engineers, Part D: Journal of Automobile Engineering. 211(3): 205-218.
