Design, Investigation and Implementation of Hetrogenous Antennas for Diverse Wireless Applications. Simulation and Measurement of Heterogeneous Antennas for Outdoor/indoor Applications, including the Design of Dielectric Resonators, Reconfigurable and multiband DR antennas, and Investigation of Antenna Radiation Performance and Design Optimization
Kosha , Jamal S.M.
Kosha , Jamal S.M.
Publication Date
2022
End of Embargo
Supervisor
Rights
The University of Bradford theses are licenced under a Creative Commons Licence.
Peer-Reviewed
Open Access status
Accepted for publication
Institution
University of Bradford
Department
Department of Biomedical and Electronics Engineering. Faculty of Engineering and Informatics
Awarded
2022
Embargo end date
2025-06-19
Collections
Additional title
Abstract
The main goals of this thesis are to design and examine heterogeneous antennas for different wireless applications of a wide variety of EM spectrum requirements: which includes WLAN 5.0 GHz, WLAN (2.45 GHz), UMTS (1.92-2.17 GHz), 2G, UMTS, LTE, ultra-wideband (UWB) applications, and MBAN applications (2.4 GHz). Various techniques for expanding bandwidth, enhancing performance, and balancing the operation have been examined through comprehensive simulated and physically fabricated models.
Thereafter, a compact DRA, for UWB applications is examined. The combined resultant effects of asymmetric positioning of DRs (2, 3 and 4 Cylindrical elements), defected ground technique, dimensions, and profile of the aperture give RF designers detailed scope of the optimization process. More resonances are achieved, and the bandwidth is improved. The obtained results show that, an impedance bandwidth of 133.0%, which covers the Ultra Wideband band (3.6GHz - 18.0GHz), with a maximum power gain of 9dBi attained.
In addition, a compact conformal wearable CPW antenna using EBG-FSS for MBAN applications at 2.4GHz is proposed. They are designed using fabric materials suitable for daily clothing. The performance of the antenna is investigated in free space, on a layered biological tissue model, and on a real human body to evaluate SAR. When the antenna is combined with an EBG-FSS structure, isolation between the antenna and the human body is introduced. The results show that the FBR is enhanced by 13 dB, the gain by 6.55dBi, and the SAR is lowered by more than 94%. The CPW antenna demonstrated here is appropriate for future MBAN wearable systems.
The design, investigation, and application of water level monitoring utilizing subsurface wireless sensor are covered in this thesis. A wideband double inverted-F antenna is designed and examined to overcome signal attenuation issues. The obtained result is feasible, which has an operating bandwidth of 0.8 to 2.17GHz, with a reflection coefficient better than 10 dB. Moreover, a field trial is conducted to evaluate the robustness of the antenna under extreme conditions. A very good efficiency was also demonstrated, with losses of under 20%. Further, the results from the field experiment established that the antenna is a reliable contender for wireless communication in such challenging environments.
Version
Citation
Link to publisher’s version
Link to published version
Link to Version of Record
Type
Thesis
Qualification name
PhD
Notes
The full text will be available at the end of the embargo: 19th June 2025
