FEM and CFD Co-simulation Study of a Ventilated Disc Brake Heat Transfer
Tang, Jinghan Qi, Hong Sheng
Tang, Jinghan
Qi, Hong Sheng
Publication Date
2013
End of Embargo
Supervisor
Rights
© 2013 FISITA. Reproduced with the permission of the publisher and in accordance with the publisher's self-archiving policy.
Peer-Reviewed
yes
Open Access status
Accepted for publication
2013
Institution
Department
Awarded
Embargo end date
Additional title
Abstract
This paper presents a two-way thermally-coupled FEM-CFD co-simulation method for ventilated brake disc rotor heat transfer analysis. Using a third party coupling interface for data mapping and exchange, the FEM and CFD models run simultaneously under a standard heavy duty braking test condition. By comparison with conventional one-way coupling methods and experimental results, the performance of the co-simulation system has been investigated in terms of prediction of the heat transfer coefficient (HTC) and disc temperatures as well as computing time used. The results illustrate that this co-simulation method has good capacity in providing cooling effect and temperature predictions. It also shows that the data exchange between the FEM and CFD codes at every time increment is highly accurate and efficient throughout 10 brake applications. It can be seen that the cosimulation method is more time efficient, convenient and robust compared to previous oneway coupling methods. To utilize the potential of this method, future works are proposed.
Version
Accepted Manuscript
Citation
Tang J and Qi HS (2013) FEM and CFD Co-simulation Study of a Ventilated Disc Brake Heat Transfer. EuroBrake 2013, Dresden Germany, 17-19 June 2013. In: EuroBrake 2013 Conference Proceedings. FISITA. ISBN: 978-0-9572076-0-8.
Link to publisher’s version
Link to published version
Link to Version of Record
Type
Conference paper
