Design of Planar Double Inverted-F Antenna for Ultra-Wideband Applications
See, Chan H. Zhou, Dawei Excell, Peter S.
See, Chan H.
Zhou, Dawei
Excell, Peter S.
Publication Date
22/09/2010
End of Embargo
Supervisor
Rights
© 2010 The authors. Reproduced by permission from the copyright holder.
Peer-Reviewed
Yes
Open Access status
Accepted for publication
Institution
Department
Awarded
Embargo end date
Additional title
Abstract
A novel miniaturized planar double inverted-F antenna is presented. The antenna design is based on the electromagnetic coupling of two air dielectric PIFA antennas, combined with a broadband rectangular plate feed structure to achieve ultra-wideband characteristics. The computed and experimental impedance bandwidths show good agreement over an UWB frequency band from 3.1 GHz to 10.6 GHz for |S11| < -10dB. The antenna is electrically small, with size 0.31 x 0.16 x 0.09 wavelengths at 3.1 GHz and 1.06 x 0.55 x 0.31 wavelengths at 10.6 GHz. The simulated and measured gain and radiation patterns show acceptable agreement and confirm that the antenna has appropriate characteristics for short range wireless applications.
Version
Accepted Manuscript
Citation
See, C. H., Abd-Alhameed, R. A., Zhou, D. and Excell, P. S. (2010). Design of Planar Double Inverted-F Antenna for Ultra-Wideband Applications. In: Asia-Pacific Radio Science Conference, Toyama, Japan, Sept 2010. Paper Number Y0007, ISBN 978-953-7619-76-3.
Link to publisher’s version
Link to published version
Link to Version of Record
Type
Conference paper
