Cocrystal habit engineering to improve drug dissolution and alter derived powder properties

Objectives: Cocrystallization of sulfadimidine (SDM) with suitable coformers, such as 4-aminosalicylic acid (4-ASA), combined with changes in the crystal habit can favourably alter its physicochemical properties. The aim of this work was to engineer SDM:4-ASA cocrystals with different habits in order to investigate the effect on dissolution, and the derived powder properties of flow and compaction. Methods: Cocrystals were prepared in a 1:1 molar ratio by solvent evaporation using ethanol (habit I) or acetone (habit II), solvent evaporation followed by grinding (habit III) and spray-drying (habit IV). Key findings: Powder X-ray diffraction showed Bragg peak position was the same in all the solid products. The peak intensity varied, indicating different preferred crystal orientation confirmed by SEM micrographs: large prismatic crystals (habit I), large plate-like crystals (habit II), small cube-like crystals (habit III) and microspheres (habit IV). The habit III exhibited the fasted dissolution rate; however, it underwent a polymorphic transition during dissolution. Habits I and IV exhibited the highest Carr’s compressibility index, indicating poor flowability. However, habits II and III demonstrated improved flow. Spray drying resulted in cocrystals with improved compaction properties. Conclusions: Even for cocrystals with poor pharmaceutical characteristics, a habit can be engineered to alter the dissolution, flowability and compaction behavior.

URI

http://hdl.handle.net/10454/13683

Version

Accepted manuscript

Citation

Serrano DR, O’Connell P, Paluch KJ et al (2016) Cocrystal habit engineering to improve drug dissolution and alter derived powder properties. Journal of Pharmacy and Pharmacology. 68(5): 665-677.

Link to Version of Record

https://doi.org/10.1111/jphp.12476

Type

Article
